Key Features High-Efficiency Sample Processing  Optional ISE module: 600 T/H 105 cuvettes: quartz glass or plastic Whole Blood Testing-HbA1c Direct testing with whole blood samples; automatic on-board hemolysis and analysis No manual pre-treatment required, ensuring higher accuracy  Simplified operation and improved testing efficiency IFCC and NGSP standardization Air Bath Heating System Constant-temperature air bath with rapid heating reduces instrument warm-up time and requires no maintenance The temperature control system utilizes dry heating to maintain the reaction solution in the cuvette at 37 ℃ Compact and Connectable Integrated with the MAGICL 6000i to form the Metis 600, the smallest clinical chemistry and immunochemistry modular system on the market—maximizing space savings while also shortening turnaround time 8-Step Warm Liquid Washing Cross-contamination rate < 0.01% Water consumption: 15 L/H and 2-step washing solution + 4-step purified water washing Intelligent 3D full-needle washing technology and ultrasonic cleaning system Automatic wash solution dilution Accurate Sampling System Minimum reaction volume: 100 μL Highly-precise injector, internally and externally polished sampling probes, liquid level detection and bubble detection Advanced Optical System LED light source with high stability, long lifespan optical system with diffraction grating and 16 wavelengths Application Scenarios Hospital Labs Diagnostic Centers Academic Research Institutes Test Menu Technical Specifications Test Principles: Latex immunoturbidimetry, immunoturbidimetry, colorimetry Test Methods: Rate method, end point method, fixed-time method Dimensions: 960 mm (L) * 770 mm (W) * 655 mm (H) Sample Positions: 50 positions  Reagent Positions: 80 positions Sample Types: Serum, plasma, whole blood, urine, and  cerebrospinal liquid samples Application Scenarios: Hospital Labs, Diagnostic Centers, Academic Research Institutes    Water Consumption: No more than 15 L purified water per hour Minimum Reaction Volume: 100μL

Key Features Intelligent Sampling System Constant throughput with built-in ISE 400 T/H Automatic decapping and recapping Automated sample system with probe clogging detection, liquid level monitoring Multilayered Dry Chemistry Technology Dry chemistry system reduces HIL interference for more accurate results, shortens sample turnaround time and uses no water Compact and Connectable Small footprint only takes up 0.42 ㎡ and offers flexible installation with plug-and-play operation  Connectable with MAGlCL 6000 to form the Metis 600⸺One tube of whole blood sample to test, also connectable with Getein 1200 which enables liquid-free testing Advanced Optical System A durable LED light source ensures 60000 hours long lifespan, stable illumination, and low maintenance cost Application Scenarios Hospital Labs Diagnostic Centers Academic Research Institutes Test Menu Technical Specifications Test Principles：Colorimetry; Direct ISE method Dimensions: 628 mm (L) * 671 mm (W) * 810 mm (H) Sample Positions: 50  Sample Type：Whole blood/Serum/Plasma/Urine Minimum Sample Volume: 10 μL per test Reagent Positions: 40 Light Source: LED

Key Features Easy and Quick Simple operation: add sample → perform the test → get result in 12 min Micro Blood Collection 100 μL microvolume sampling, small animals friendly Multiple Packages A variety of check-up packages：one sample, multiple indicators Compact Appearance Portable and compact appearance, meet the needs of animal hospitals Accurate Results With professional intelligent quality control system to guarantee the accuracy of results Test Menu Techinical Specifications Test Principles: Absorption spectrophotometry Sample Volume: 100 µL Sample Types: Whole blood, serum, plasma Languages: Chinese, English Screen Size: 7-inch android screen, 1024 mm * 600 mm resolution Printer: Built-in thermal printer, supports Wi-Fi data transmission for printing A4 reports on Ani-Q Power Supply: 100-240 VAC, 50 Hz~60 Hz; Input Power: 200 VA

Key Features High-effciency Sample Processing  Constant throughput: 400 T/H, optional ISE module with 400 T/H 90 samples positions, 80 reagent positions Dry Heating Thermostatic System Direct heating system enables faster heating and decreases pre-heating time Thermostatic system by dry heating keeps reaction solution in cuvettes at (37.0±0.2）℃ Accurate Sampling System Internally and externally polished sampling probes, high-precision Liquid volume tracking and level detection Bubble detection and probe-clot (clogging) detection Water-quality monitoring module (Optional) and Built-in degassing unit  Advanced Optical system Optical system with diffraction grating and 16 wavelengths Glass reaction cuvettes with permanent use Intelligent Online Loading System Reagents can be loaded on-board during test Peltier system provides a longer maintenance period to reduce repair probability 8-step Warm Liquid Washing Whole probe stereo cleaning technology with cross-contamination rate＜0.01% Anti-overflow function prevents liquid spillage Application Scenarios Hospital Labs Diagnostic Centers Academic Research Institutes Test Menu Technical Specifications Test Principles: Latex immunoturbidimetry, immunoturbidimetry, colorimetry Test Methods: Rate method, end point method, fixed-time method Dimensions: 1160 mm (L) * 790 mm (W) * 1140 mm (H) Gross Weight: 300 kg Sample Positions: 90 positions  Reagent Positions: 80 positions Sample Types: Serum, plasma, whole blood, urine, and  cerebrospinal liquid samples Application Scenarios: Hospital Labs, Diagnostic Centers, Academic Research Institutes    Water Consumption: No more than 15 L purified water per hour Calibration: multi-point calibration curve with up to 7 points Dilution: automatic pre-dilution Minimum Reaction Volume: 100μL Minimum Sampling Volume: 1.5μL

Key Features Better Cost-effectiveness  One stirrer less — Upgraded mechanics with reduced maintenance High-effciency Sample Processing Constant throughput: 400 T/H, optional ISE module with 400 T/H 90 sample positions, 80 reagent positions Dry Heating Thermostatic System Direct heating system enables faster heating and decreases pre-heating time Thermostatic system by dry heating keeps reaction solution in cuvettes at (37.0±0.2）℃ Accurate Sampling System Internally and externally polished sampling probes, high-precision Liquid volume tracking and level detection Bubble detection and probe-clot (clogging) detection Water-quality monitoring module (Optional) and Built-in degassing unit  Advanced Optical system Optical system with diffraction grating and 16 wavelengths Glass reaction cuvettes with permanent use Intelligent Online Loading System Reagents can be loaded on-board during test Peltier system provides a longer maintenance period to reduce repair probability 8-step Warm Liquid Washing Whole probe stereo cleaning technology with cross-contamination rate＜0.01% Anti-overflow function prevents liquid spillage Application Scenarios Hospital Labs Diagnostic Centers Academic Research Institutes Test Menu Technical Specifications Test Principles: Latex immunoturbidimetry, immunoturbidimetry, colorimetry Test Methods: Rate method, end point method, fixed-time method Dimensions: 1160 mm (L) * 790 mm (W) * 1140 mm (H) Gross Weight: 300 kg Sample Positions: 90 positions  Reagent Positions: 80 positions Sample Types: Serum, plasma, whole blood, urine, and  cerebrospinal liquid samples Application Scenarios: Hospital Labs, Diagnostic Centers, Academic Research Institutes    Water Consumption: No more than 15 L purified water per hour Calibration: multi-point calibration curve with up to 7 points Dilution: automatic pre-dilution Minimum Reaction Volume: 100μL Minimum Sampling Volume: 1.5μL

Key Features Standardization Improve laboratory efficiency through the highest level of automation Reliability Maximize reliable results with industry-leading instrument accuracy and service Rapid Accelerate turnaround time for high-volume sample testing and achieve new levels of rapid service Flexibility Unlock limitless lab possibilities through customizable configurations  Application Scenarios Hospital Labs Diagnostic Centers Check-up Centers Test Menu

Key Features High-effciency Sample Processing  Constant throughput: 800 T/H, optional ISE module with 400 T/H 137 samples positions, 114 reagent positions Dry Heating Thermostatic System Direct heating system enables faster heating and decreases pre-heating time Thermostatic system by dry heating keeps reaction solution in cuvettes at (37.0±0.2）℃ High-efficiency Triple Mix Bars Triple mix bars with two-stage cleaning, avoiding stirring rod contamination Real-time monitoring of stirring speed Accurate Sampling System Internally and externally polished sampling probes, high-precision Liquid volume tracking and level detection Intelligent Online Loading System Reagents can be loaded on-board during test 9-step Warm Liquid Washing Whole probe stereo cleaning technology with cross-contamination rate＜0.01% Anti-overflow function prevents liquid spillage Advanced Optical system  Optical system with diffraction grating and 16 wavelengths Glass reaction cuvettes with permanent use (optional) Application Scenarios Hospital Labs Diagnostic Centers Academic Research Institutes Test Menu Technical Specifications Test Principles: Latex immunoturbidimetry, immunoturbidimetry, colorimetry Test Methods: Rate method, end point method, fixed-time method Dimensions: 1640 mm (L) * 940 mm (W) * 1215 mm (H) Gross Weight: 500 kg Sample Positions: 137 positions  Reagent Positions: 114 positions Sample Types: Serum, plasma, whole blood, urine, and  cerebrospinal liquid samples Application Scenarios: Hospital Labs, Diagnostic Centers, Academic Research Institutes    Water Consumption: No more than 26 L purified water per hour Dilution: automatic pre-dilution Minimum Reaction Volume: 100μL Minimum Sampling Volume: 1.5μL

Key Features Automatic Automatic & Streamlined workflow to reduce workload Independent emergency track, striving for more treatment time Flexible Flexible expansion enables the combination and collaboration of 1-4 modules Optional choice for SHC 200 system (Centrifuge & Decapper) Compact Metis 6000 takes up only 2.6 m2 for two modules Only increasing 1.0 m2 by upgrading with SHC 200 system (Centrifuge & Decapper) Intelligent Optional SHC 200 pre-analytical module can realize Automatic tube decapping and cap disposal Automatic sample centrifugation Centrifugation time, speed and temperature can be set according to needs Application Scenarios Hospital Labs Diagnostic Centers Check-up Centers Test Menu Technical Specifications MAGICL 6200 Immunochemistry Module Test Principle: Acridinium ester direct chemiluminescence Throughput: Up to 400 T/H Fastest Time of First Result: 10 min Reaction Cup: Using mainstream circular reaction cup, up to 2000 pieces can be stored at a time Reagent Tray: 30 reagent positions with 2-8 ℃ internal air circulation refrigeration Dimensions: 1100 mm(L)×930 mm(W)×1200 mm(H) CM-1000 Clinical Chemistry Module Throughput: Constant speed of 1000 T/H; optional ISE module: 400 T/H Simultaneously Detected Items: 61 Cuvettes: 270 quartz glass or plastic cuvettes (optical path: 5 mm)  Reagent Tray: 63 reagent positions for outer tray (20/70 mL) 40 reagent positions for inner tray (20/70 mL)  Dimensions: 1100 mm(L)×930 mm(W)×1200 mm(H)
