Key Features Fast Test Utilizing double-channel test mode No Residue No residue of hematology diluent or lysing reagent；Cost effective Easy and Convenient Operation Large LCD touch screen High-definition color monitor, no need of external computer Built-in printer to fast print test results Supports Wi-Fi data transmission for printing A4 reports on Ani-Q Optimized Liquid System Very low failure rate & excellent maintainability Intelligent Floating Threshold Making the classification more accurate Techinical Specifications 19 Reportable Parameters: WBC, NEU#, MXD#, LYM#, NEU%, MXD%, LYM%, RBC, HGB, MCV, RDW-CV, MCHC, MCH, RDW-SD, HCT, PLT, MPV, PDW, PCT Principles: Classic Electrical Impedance Method, Mature Photoelectric Colorimetry Sample Mode: Whole Blood Sample Volume: Venous blood: 10 μL QC Methods: L-J QC, X-B QC Data Storage: 10000 Screen Type: 10.4 inch Resistive Screen Power Supply: 100-240 V~ 50/60 Hz Weight: 16 kg Dimension: 328 mm x 425 mm x 446 mm (L x W x H) Operating Conditions: 18~30℃, ≤80％ Relative Humidity, 75 kPa~106 kPa

Key Features Humanization Venous blood sample volume: 15 uL Less pain during blood collection Sample type: venous blood/capillary blood (pre-dilution mode) to meet different needs Technology Innovation Intelligent scatter classification technology Curve-fitting&floating threshold technique Advanced methods Laser Scattering Method: Obtain information on the size and internal composition of WBC and classify them Digital Filtering: Effectively remove interference from impurity signals Optical Method for BASO: Avoid errors caused by the partial overlap of basophil and leukocyte High Efficiency and No Residue 60 T/H No hematology diluent or lysis reagent residues Blood Cell Overlap Correction Technology Make accurate judgments when cells overlap through the well Multi-Segment counting Better exclude biased results and improve test accuracy Smallest Gem Hole The industry's smallest gem hole of 50 um Display 10.4" capacitive touch screen, improve the sensitivity of touch operation Support operation with rubber gloves Species of Animals Dog, cat, pig, horse, sheep, rabbit, camel, one self-programmed animal Technical Specifications 23 Whole Blood Reportable：WBC、LYM%、LYM#、NEU%、NEU#、MON%、MON#、EOS%、EOS#、BAS%、BAS#、RBC、HGB、HCT、MCV、MCH、MCHC、RDW-SD、RDW-CV、PLT、PDW、MPV、PCT Sample Volume: Venous blood: 15 μL; capillary blood (pre-dilution): 20 μL Principles： Laser scatter in flow cytometry，classic electrical impedance method，mature photoelectric colorimetry Power Supply：220V±22～AC,50±1 Hz，larger voltage range can be supported by transformers Sample Volume：Whole blood: 15μL； diluted blood: 20μL Dimensions：328 mm (L) x 471 mm (W) x 446 mm (H)   Performance：Parameter precision (CV%)，WBC ≤4.0，RBC ≤2.0，HGB ≤2.0，PLT (10^3/μL) ≤8.0，MCV ≤3 Display：10.4 inch capacitive touch screen Quality Control：L-J QC, X-B QC Weight：21 kg
